BEXS-110DC

Item Number: 3006102014

EX Alarm Horn 24VDC 110DB, IP66/67

IP66 IP66
IP67 IP67
Atex
  • Sound level outputs of up to 117dB(A) at 1 metre
  • 32 alarm tones and 3 remotely selectable stages.
  • Marine grade, corrosion proof, LM6 aluminium enclosure.
  • Ingress protection IP66/67
  •  Stainless steel fixings
  • Stopping plug included.
  • Automatic synchronisation on multi-sounder system.

The flameproof BExS110 alarm sounders are suitable for Zone 1, 2, 21 & 22 applications. Approved to IECEx, ATEX, Ex EAC and INMETRO standards.

Available options: Voltage: 24V dc, 230V ac





General
Maximum output 117dB(A) @ 1 metre [108dB(A) @ 10ft/3m]
Nominal output 110dB(A) @ 1m +/- 3dB - Tone 2 [101dB(A) @ 10ft/3m]
No. of tones 32 (UKOOA / PFEER compliant)
No. of stages 3
Volume control Max. 110dB(A); Min. 72dB(A) - Tone 2
Effective range 100m/328ft @ 1KHz
Ingress protection IP66/67
Cable entries Dual M20 ISO (one stopping plug inc) Adaptors to M25, 1/2" & 3/4" NPT can be specified
Terminals 0.5 - 2.5mm² (20-14 AWG)
Temperature range -50° to +70°C
Weight 3.00kg
ORDER NUMBER
3006102014 EX ALARM HORN 24VDC 110DB IP66/IP67
3006102013 EX ALARM HORN 230VAC 110DB IP66/IP67

DHH1-230

DHH1-230

EX Signal horn 230VAC 50/60 HZ WT

Item Number: 2340210000

Date Name Category Size Document
BEXS110_IECEx_Cert.pdf 99.01 KB Download
BEXS110_Manual.pdf 1.74 MB Download
BEXS110_MED_Cert.pdf 156.74 KB Download
BEXS110_Datasheet.pdf 187.11 KB Download
BEXS110_DoC.pdf 246.69 KB Download
BEXS110_ATEX_Cert.pdf 536.71 KB Download
