DH 50 Horn Speaker

DH-50

Item Number: 3006100036

IP67 Horn Loudspeaker for Maritime and Industrial Applications

  • Designed for reliable sound distribution across large areas
  • Suitable for maritime and demanding industrial environments
  • IP67-rated protection against dust and water ingress
  • Fiberglass-laminated polyester construction
  • Adjustable mounting bracket for directional positioning
  • Designed for use with the DST-100 driver unit
  • RAL 7035 finish
  • Suitable for exposed environmental conditions
IP67 IP67

The DH-50 is a robust horn loudspeaker designed for reliable sound distribution across large areas in demanding maritime and industrial environments. Its large horn design provides efficient sound projection, making it suitable for applications where announcements, alarms and other audio signals need to reach personnel over extended distances.

Constructed from fiberglass-laminated polyester and designed for exposed environments, the DH-50 provides IP67 protection against dust and water ingress. The adjustable mounting bracket allows the horn to be positioned according to the required coverage area.

The DH-50 is designed for use with the DST-100 driver unit, providing a flexible solution for high-power public address and general alarm applications.

General
Material / Colour Fiberglass laminated polyester / RAL 7035
Mounting Bracket
Weight 5.15 kg
Protection IP67
Environmental Condition Exposed
Note! See data sheet DST-100 for further specification

DST-100

DST -100

100 W Driver Unit for DH-50 Horn

Item Number: 3006100043

DST-100

DST-100-MED

100 W MED-Approved Driver Unit for DH-50 Horn

Item Number: 2131000164

DH-30

Waterproof Horn

Item Number: 3006100035
