EDS-405A

Item Number: 2220013001

Moxa 5-port Din-Rail Mount Marine Ethernet Switch

The EDS-405A/408A are entry-level 5 and 8-port managed Ethernet switches designed especially for industrial applications. The switches support a variety of useful management functions, such as Turbo Ring, Turbo Chain, ring coupling, IGMP snooping, IEEE 802.1Q VLAN, portbased VLAN, QoS, RMON, bandwidth management, port mirroring and warning by email or relay. The ready-to-use Turbo Ring can be set up easily using the web-based management interface, or with the DIP switches located on the top panel of the EDS-405A/408A switches.

The MOXA EDS-405A is managed 5-port switch for Marine use (DNV-GL).

Dimensions & weight
Dimensions (W x D x H) 53.6 x 105 x 135 mm
Weight 650 g
Mounting DIN-rail and wall mounting (with optional kit)
Housing Metal, IP30 protection
Electrical characteristics
Input voltage 24 VDC (12 to 45 VDC), redundant dual inputs
Current 0.24 A @ 24 V

EDS-405A

Date Name Category Size Document
23.05.2023 MD-SDoC-2220013001-IHM-8003-41783-126538 Declaration 72.17 KB Login to download
8.05.2020 EDS-405A and EDS-408A Series Data Sheet Datasheet 1.06 MB Download
