Esprit Anti-Corrosion PTZ

ESSE1-2X40-SPT-M2 ESPRIT AC ENH1 2MPx40 SS PTZ 230VAC

Item Number: 2310111200

ESPIRIT ANTI-CORROSION PTZ, 1080p, wiper, 230V, IP68

  • Stainless steel network PTZ camera
  • Maximum resistance in corrosive environments
  • Integrated video analytics available
  • Wide dynamic range and low light compensation
  • ONVIF compliant
  • Lloyd's Register Marine Type Approval
  • Electromagnetic compatibility: EN60945
  • Environmental: IEC 60068-2-78
  • IP66-69
ONVIF Conformant
IP66 IP66
IP67 IP67

The Esprit Anti-Corrosion PTZ is a corrosion-resistant Day/Night Pan-Tilt-Zoom (PTZ) camera with 40x zoom and full 1080p resolution to accurately identify details in dark environments. Designed with AISI 316L stainless steel and micro-shot peened, electro-polished surfaces, it offers maximum resistance in corrosive environments, ideal for effective video monitoring in offshore/onshore marine environments and for ports and roadways. In addition, the Esprit Anti-Corrosion PTZ offers IP66/IP67/IP68/IP69 certifications and a NEMA Type 4X rating, ensuring protection against extreme conditions, including water and dust.

Description
Supply voltage/Current consumption 220-230Vac, 0.5A max, 50/60Hz
Power consumption 120W max
Ethernet connection RJ45 100 Base-TX
Protocols IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv2, ICMP, DHCP, Zeroconf, ARP, HSTS
Streaming protocols RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP
Electronic Shutter Control Automatic, Manual (1/1 to 1/10,000 sec)
Image resolution From 384x216 pixel to 1920x1080pixel
Selectable frame rate From 1 to 60 images per second (fps)
External I/O Terminals 1 Alarm In, 1 Alarm Out, 1 Washer pump Out, 1 Remote reset In
Resolution Full HD 1080p (1920x1080pixel)
Image Device 1/2.8" progressive scan CMOS
Active Pixels 1937 (H) × 1097 (V)
Minimum Illumination 0.03 lux (F/1.6) in color mode
Lens 4.25 to 170 mm, F/1.6 – F/4.95, autofocus
Zoom Up to 40x
Iris Automatic, Open, Closed
Horizontal Viewing Angle From 66.35° to 1.9°
Vertical Viewing Angle From 39.99° – 1.11°
Video Compression H.264 and H.265 Pelco Smart Compression, Motion JPEG
Streaming Multi-stream H.264, Multi-stream H.265, Motion JPEG
Wide Dynamic Range 120dB
Operating temperature Continuous working: from -40°C (-40°F) up to +65°C (149°F)
Relative humidity from 5% up to 95% non-condensing
Weight 22,8kg
