TWIN-EExII-A

Item Number: 4000014737

EX Telephone Alarm Sounder/Strobe Beacon, 230VAC, Amber

IP66 IP66
Atex
  • For universal industrial use
  • II 2 G Ex e mb [ib] IIC T6/T5/T4 Gb
  • Protection class IP 66 according to EN 60529
  • Explosion-proof, optical-acoustic signalling unit
  • High-volume multitone alarm
  • Powerful strobe light
  • 230 VAC power supply

The TWIN-EExll is a compact unit comprising power supply, telephone connection, strobe light, amplifier and loudspeaker. The bottom box is made of seawater-resistant cast aluminium coated with plastic. The loudspeaker consists of impact and cold-resistant plastic and is permanently mounted to the housing. The strobe light cap made of polycarbonat forms the housing cover.


General
Type of ignition protection ≤ 60 min at Ta +60°C; ≤ 15 min at 60 Hz (30 min pause)
Visual signal transmitter 2 flashtubes with 1J
Mains connection 230 VAC -15% +10%, 50/60 Hz
Telephone connection 30 VAC - 75 VAC; 23-54 Hz 0-63 VDC
Housing Die-cast aluminium grey
Type of mounting vertical
Cable entry 2x cable glands M20 x 1.5 6–12 mm (main circuit); 5–10 mm (telephone circuit)
Connection technology up to 1.5 mm² single or fine wire
Strobe/flash frequency 1-2 Hz
Tone 3 Tones, One tone, Two tones or Three tones Can be adjusted with DIP switch
Duty cycle ≤ 60 min at Ta +60°C; ≤ 15 min at 60 Hz (30 min pause)
Operating temperature -20 °C/+60 °C
Degree of protection IP66
Weight 1,42 kg
Audible signal transmitter Loudspeaker
Tone ringing volume 90 dB
