EX Thermostat

EX-THERM

Item Number: 2810011018

EX Thermostat, IP66, Max. 250VAC, 10A

  • For use in hazardous areas
  • For use in wet areas (IP66)
  • DIN rail and screw mounting
  • Maintenance free
IP66 IP66
Atex

The EX-THERM is a compact, small mechanical thermostat offering a high response accuracy, small switching difference, and a very long service life (switching cycles). This thermostat of temperature class T6 (185 °F / 85 °C max.) is utilized for the regulation of heaters deployed in hazardous areas or where a high IP rating is needed.

Applications:

  • Enclosures and control cabinets in explosive environments
  • Encloser and cabinet where watertight thermostat is needed



    Specification
    Model Stego 01185.0-00
    Contact type (1-pole) Normally Closed (NC)
    Switch temperature 15 °C / 59 °F
    Technical Data
    Temperature class T6
    Ex Protection type II 2 GD Gases Ex db IIC T6 Gb
    Ex Protection type II 2 GD Dusts Ex tb IIIC T85 °C Db IP66
    Ambient temperature -76 to +185 °F (-60 to +85 °C)
    Sensor Element thermostatic bimetall
    Service LIfe > 100 000 cycles
    Max. switching capacity AC 250 V 10 A1
    Min. switching capacity DC 1.5 V 5 mA
    Connection silicone cable (halogen-free) 3 x AWG 18 (1.0 mm²), length 3 ft (1 m)
    Mounting clip for 35 mm DIN rail, EN 60715 screw mounting M5, optional sideways mounting
    Housing aluminum, silver anodized
    Dimensions 95 x 45 x 30 mm (3.7 x 1.8 x 1.9")
    Weight approx. 0.3 kg / 0.66 lbs
    Protection type / Protection class IP66 / I (grounded)
    Approvals EPS 16 ATEX 1 118 X
    IECEx EPS 16.0054X
    EAC

    2810011018_Ex_Thermostat_DimDraw
